Specifications
| Image Sensors | APTINA MT9F001 CMOS( |
| scan mode | Progressive progressive scan |
| Maximum resolution | 4096 x 3288 (Approx. 14,000,000 Pixels) |
| Sensors size | 1/2.3“ (6.138mm(H) x 4.603mm(V), Diagonal 7.672mm) |
| pixel size | 1.4μm x 1.4μm |
| Sensitivity | 0.724v/lux-sec(550nm) |
| Dynamic range | 65.3dB |
| analog to digital conversion | 12-bit, 8-Bit R.G.B to PC |
| signal-to-noise ratio | 35.5dB |
| Light spectrum Response range | 380-650nm (with IR-filter) |
| Video format and frame rate | 1.8fps @4096 x 3288, 10fps @2048 x 1644, 27fps @1024 x 822 |
| pixel overlay | 1 x 1, 2 x 2, 4 x 4 |
| exposure capability | 0.4~2000ms, ROI Auto & Manual |
| White equilibrate | One Push ROI White Balance/ Manual Temp-Tint Adjustment |
| Color rendering technology | Ultra FineTM Color Engine |
| peak quantum efficiency | 35% |
| read noise | N/A |
| extinction ratio | N/A |
| software interface | DirectShow , Twain |
| recording mode | Still Picture and Movie |
| Refrigeration system | Nature, Optional: PELTIER (Semiconductor Cooling Module) |
| Operating temperature | -10℃~ 50℃ |
| Storage temperature | -20℃~ 60℃ |
| Operating humidity | 30~80%RH |
| Storage Humidity | 10~60%RH |
| Power | DC 5V over PC USB port |
| Operating system | Microsoft® WINOOWs® XP / Vista / 7 (32 & 64 bit)OS X (Mac OS X)Linux (2.6或以上核) |
| Computer configuration | CPU: Equal to Intel Core2 2.8GHz or higher、Memory:2GB or more、USB port:USB2.0 High-speed Port、Display:17" or larger、CD-ROM、 |
Packing list
host X1, operation manual X1, warranty card X1, certificate of conformity X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/25536/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
