Specifications
| Image Sensors | APTINA MT9F001 CMOS( |
| scan mode | Progressive progressive scan |
| Maximum resolution | 2592x1944(Approx. 5,000,000 Pixels) |
| Sensors size | 1/2.5“ (5.7mm(H) x 4.28mm(V), Diagonal 7.672mm) |
| pixel size | 2.2μm x 2.2μm |
| Sensitivity | 0.53v/lux-sec(550nm) |
| Dynamic range | 66.5dB |
| analog to digital conversion | 12-bit, 8-Bit R.G.B to PC |
| signal-to-noise ratio | 40.5dB |
| Light spectrum Response range | 380-650nm (with IR-filter) |
| Video format and frame rate | 5fps @2592 x 1944, 18fps @1280 x960, 60fps @640x480 |
| pixel overlay | 1 x 1, 2 x 2, 4 x 4 |
| exposure capability | 0.294~2000ms, ROI Auto & Manual |
| White equilibrate | One Push ROI White Balance/ Manual Temp-Tint Adjustment |
| Color rendering technology | Ultra FineTM Color Engine |
| peak quantum efficiency | 35% |
| read noise | N/A |
| extinction ratio | N/A |
| software interface | DirectShow , Twain |
| recording mode | Still Picture and Movie |
| Refrigeration system | Nature, Optional: PELTIER (Semiconductor Cooling Module) |
Packing list
host X1, operation manual X1, warranty card X1, certificate of conformity X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/25538/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
