Specifications
| Image Sensors | APTINA MT9F001 CMOS( |
| scan mode | Progressive progressive scan |
| Maximum resolution | 2048x1536(Approx. 3,000,000 Pixels) |
| Sensors size | 1/2“ (5.7mm(H) x 6.55mm(V), Diagonal 4.92mm) |
| pixel size | 3.2μm x 3.2μm |
| Sensitivity | 1.0v/lux-sec(550nm) |
| Dynamic range | 61dB |
| analog to digital conversion | 12-bit, 8-Bit R.G.B to PC |
| signal-to-noise ratio | 43dB |
| Light spectrum Response range | 380-650nm (with IR-filter) |
| Video format and frame rate | 8fps @2048 x 1536, 22ps @1024 x768, 43fps @680x510 |
| pixel overlay | 1 x 1, 2 x 2, 3 x 3 |
| exposure capability | 0.244~2000ms, ROI Auto & Manual |
| White equilibrate | One Push ROI White Balance/ Manual Temp-Tint Adjustment |
| Color rendering technology | Ultra FineTM Color Engine |
| peak quantum efficiency | 35% |
| read noise | N/A |
| extinction ratio | N/A |
| software interface | DirectShow , Twain |
| recording mode | Still Picture and Movie |
| Refrigeration system | Nature, Optional: PELTIER (Semiconductor Cooling Module) |
Packing list
host X1, operation manual X1, warranty card X1, certificate of conformity X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/25539/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
