Specifications
| Chip model | IMX183CQJ-J |
| Chip type | CMOS |
| chip size | 1" |
| Color type | color |
| pixel size | 2.4x2.4(μm) |
| Resolution | 5496(H)x3672(V) |
| camera frame rate | 15fps(5496x3675)53fps(2736x1824 2x2bin)67fps(1920x1680 3x3bin) |
| Shutter mode | Roller shutter |
| exposure time | 0.13ms-15s |
| automatic setting | Exposure, color level, white equilibrate |
| manual setting | Exposure, gain, noise reduction, gamma, flat-field correction |
| Color temperature | 2000-15000K |
| PC software | Capture V 2.0 |
| image format | JPG / PNG / TIFF |
| Operating system | Supports Windows, Linux/Mac development |
| PC requirements | CPU: Intel i5 4 core and above, RAM: 8G and above, OS: 64-bit Win7/8/10 |
| multi-camera | Supports running 4 cameras simultaneously on the SDK |
| Interface | USB3.0 |
| Optical inspection interface | Standard C interface |
| Camera size | 68x68x46mm |
| Camera Weight | 330g |
Packing list
machine X1, operation manual X1, warranty card X1, certificate of conformity X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/25543/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
