Specifications
| Pt100 Measurement range | -100 ~ +400 ℃ |
| Pt100 Measurement Accuracy | ±0.2 ℃ (-100 ~ +200 ℃) ±1 Digit±0.3 ℃ (+200.1 ~ +400 ℃) ±1 Digit |
| PT100 resolution | 0.01 ℃ |
| Weight | 220 g |
| diameter | 103*63*33 mm |
| Environmental temperature | -35~+70℃ |
| Shell material | Plastic |
| Protection level | IP65 |
| Number of channels | 2 channels, external |
| Attachable probe | 2 x Pt100 temperature probe |
| standard | EU Directive 2014/30/EU; 2011/65/EU; DIN EN 12830 |
| Measurement ratio | 1s~24h; 2 s to 24 h (online measurement) |
| Power Supply | TL-5903 |
| Battery life | 8 years (measurement period is 15 minutes, + 25 ℃) |
| interface | mini usb, SD card slot |
| Data storage | 2,000,000 Measured value |
| Storage temperature | -40~+85℃ |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
