GreatWall CHS-30D Digital Display Top-mounted Electronic Stirrer

Model：
Contact
Details SPEC

GreatWall CHS-30D Digital Overhead Electronic StirrerSPEC

GreatWall CHS-30D Digital Overhead Electronic StirrerDetails

GreatWall CHS-30D Digital Overhead Electronic StirrerPacking list

SKU
NB026388
Processing Capacity
10L
maximum viscosity
10000mPa·s
Max Torque
85  N.cm
Speed range
200~3000rpm
drive type
Electronically driven DC motor
Motor input/output power
83/75W,   1/10HP
Timer
99 hours and 59 minutes (continuous operation), error status & Timer end prompt
Control system
Digital Fuzzy Controller, Jog-Shuttle Switch (turn + press)
Maximum Permissible Impeller Shaft Diameter
8mm
Environmental temperature
0~40℃
Safety protection
Motor overheating & overload protection function
material
ABS and aluminum
Dimensions
90*145*180mm
Packaging Dimensions
320×300*180mm
Power
85W
Power supply Voltage
220~240V 50/60Hz
Allowable Relative Humidity
≤80%
Machine Weight
4.5kg
alarm
Error Status & Timed End Prompt
Gross Weight
5kg
CHS-30D
Digital Overhead Electronic Stirrer
GreatWall CHS-30D Digital Display Top-mounted Electronic Stirrer Picture

Usage characteristics:

It is suitable for the process of material mixing and stirring reaction in the laboratory.

●Adopt liquid crystal display mode.

●Jog-Shuttle control system is adopted, which can achieve uniform mixing speed and smooth lifting process.

●It has the functions of over-temperature protection and over-current protection.

●It has the function of timing end prompt.

●It has the function of fault alarm.

●The height of the stirring paddle is adjustable.

●The chucking paddle head is chrome-plated to prevent corrosion.


FAQ
QCan this digital display top-mounted electronic Stirrer be applied to GB/T11543?
A OK
