CHS-100D
GreatWall CHS-100D Digital Overhead Electronic StirrerSPEC
GreatWall CHS-100D Digital Overhead Electronic StirrerDetails
GreatWall CHS-100D Digital Overhead Electronic StirrerPacking list
- SKU
- NB026390
- Processing Capacity
- 20L
- maximum viscosity
- 50000mPa·s
- Max Torque
- 145N.cm
- Speed range
- 200~3000rpm
- drive type
- Electronically driven DC motor
- Motor input/output power
- 130/120W, 1/6HP
- Timer
- 99 hours and 59 minutes (continuous operation), error status & Timer end prompt
- Control system
- Digital Fuzzy Controller, Jog-Shuttle Switch (turn + press)
- Maximum Permissible Impeller Shaft Diameter
- 8mm
- Environmental temperature
- 0~40℃
- Safety protection
- Motor overheat protection & overload protection function
- material
- ABS and aluminum
- Dimensions
- 90*145*180mm
- Packaging Dimensions
- 320×300*180mm
- Power
- 130W
- Power supply Voltage
- 220~240V 50/60Hz
- Allowable Relative Humidity
- ≤80%
- Machine Weight
- 5.3kg
- alarm
- Error Status & Timed End Prompt
- Gross Weight
- 8kg
CHS-100D
Digital Overhead Electronic Stirrer
Usage characteristics:
It is suitable for the process of material mixing and stirring reaction in the laboratory.
●Adopt liquid crystal display mode.
●Jog-Shuttle control system is adopted, which can achieve uniform mixing speed and smooth lifting process.
●It has the functions of over-temperature protection and over-current protection.
●It has the function of timing end prompt.
●It has the function of fault alarm.
●The height of the stirring paddle is adjustable.
●The chucking paddle head is chrome-plated to prevent corrosion.
FAQ
QCan this digital display top-mounted electronic Stirrer be applied to GB/T11543?
A
OK
