Specifications
| Light spectrum range | 315nm~400nm，λp = 365nm |
| Power Measurement range | 0~2000mW/cm² |
| Power Resolution | 0.1mW/cm² |
| Energy Measurement range | 0~999999mJ/cm² |
| Energy measurement Accuracy | ± 10%, ± 5% typical |
| Sampling speed | 2048 times/second |
| Power data storage interval | 32 times/second |
| recording period | 32 minutes |
| Instrument Power | 4 AAA alkalinity dry cells |
| show | 40 * 160 dot matrix LCD |
| Instrument size | Length 160mm × Width 75mm × Height 13mm |
| Instrument Weight | 303 g |
Packing list
UV energy meter x1, USB data cable x1, AAA battery x4, anti-static gloves x1, small cross screw driver x1, manual x1, warranty card x1, engineering box size 25 * 21 * 7 cm (length * width * height) x1
After-sales instructions
Warranty days: 365 days
