Specifications
| Light spectrum range | 340Nm~ 420nm, instrument calibrated to 395nm light source |
| Power Measurement range | 0~40000mW/cm² |
| Power Resolution | 1mW/cm² |
| Energy Measurement range | 0~999999mJ/cm² |
| Energy measurement Accuracy | ± 10%, ± 5% typical |
| Sampling speed | 2048 times/second |
| Power data storage interval | 32 times/second |
| recording period | 32 minutes |
| Instrument Power | 4 AAA alkalinity dry cells |
| show | 240 * 160 dot matrix LCD |
| Instrument size | Length 160mm × Width 75mm × Height 13mm |
| Instrument Weight | 303g |
Packing list
UV energy meter x1, USB data cable x1, AAA battery x4, anti-static gloves x1, small cross screw driver x1, manual x1, warranty card x1, engineering box size 25 * 21 * 7 cm (length * width * height) x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/26426/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
