Specifications
| Light spectrum Response | 340Nm-420nm, instrument calibrated to 395nm LED light source |
| Power Measurement range | 0~20000 mW/cm2 |
| Power Resolution | 1 mW/cm2 |
| Energy Measurement range | 0 – 9999999mJ/cm2 |
| Record time | 0 – 99999S |
| Measurement Accuracy | ±10 % |
| Sampling rate | 2048 times/second |
| Optional unit | mW / cm2 () W / cm2W / m2 |
| Test hole diameter | Φ3mm |
| Sensors size | 28*7.2*6.5mm |
| Host size | 170*76*26mm |
| Probe line length | 0.8 meters |
| Instrument Weight | Approx. 232 g (with battery) |
| show | 240 * 160 dot matrix LCD |
| Power | 4 AAA alkalinity dry cells |
Packing list
UV irradiometer x1, AAA alkalinity battery x4, manual x1, warranty card x1, engineering box size 34 * 29 * 9 cm (L * W * H) x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/26437/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
