Specifications
| Interior size | 1000*1000*1000mm |
| Temperature range | RT+10~150°C |
| Humidity control range | 85~98％R.H |
| Temperature fluctuation | ≤±0.5℃ |
| Humidity Deviation | +2、-3％R.H |
| Heating rate | 0→100℃≈35min |
| Timer | 0~9999 M, H adjustable |
| Controller | Using (7.0 inch) large screen screen, the screen operation is simple, and the program editing is easy. |
| temperature control Accuracy | ±0.1℃ |
| Temperature transducer | Platinum resistor. PT100Ω/MV |
| Heating system | Fully independent system, nickel-chromium alloy electric heating heater |
| Humidification system | Built-in isolated, all stainless steel shallow surface evaporative humidifier |
| Dehumidification system | Adopt evaporator coil dewpoint temperature laminar flow contact dehumidification method |
| Water supply system | Humidified water supply adopts automatic control |
| Refrigeration system | Fully enclosed air-cooled compression refrigeration method, original French "Taikang" unit |
| Circulatory system | Temperature-resistant and low-noise air-conditioned motor, multi-leaf centrifugal wind turbine |
| Enclosure Material | A3 steel plate electrostatic spray treatment |
| Inner box material | SUS304 stainless steel high quality mirror steel plate |
| Thermal insulation material | Polyurethane Rigid Foam/Ultrafine Glass Fiber Cotton |
| Door frame insulation | Double Layer High and Low Temperature Conditioning Silicone Rubber Door Seal |
| Total power | 4.0KW |
| Standard configuration | 1 set of illuminated Glass window, 2 test racks, 1 test lead hole φ50mm |
| Safety Devices | Leakage, short circuit, over temperature, water shortage, motor overheating, compressor overVoltage, overload, overcurrent protection |
| Power | AC220V ± 10% 50Hz AC380V ± 10% 50Hz three-phase five-wire system |
| Environment temperature | 5~30℃ |
| Environment humidity | ≤85％R.H |
| Temperature Uniformity | ≤±2℃ |
| Cooling rate | 100→0℃≈45min |
| Humidity Control Accuracy | ±1％R.H |
Packing list
Host x1, with lighting Glass window x1 set, test rack x2, test lead hole φ50mmx1, manual x1, warranty card x1
After-sales instructions
Warranty days: 365 days
1. If the instrument and equipment are not artificially caused by product quality problems, the manufacturer provides 1 year free warranty service;
2. During the warranty period, the manufacturer will arrange to deal with the equipment failure caused by the quality of the product itself within 48 hours after receiving the notice;
3. Outside the warranty period, the manufacturer will maintain it free of charge, and only charge the cost of parts and the cost of the engineer's on-site travel;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/26978/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
