Specifications
| Liner size | 800*1000*1000mm |
| Mesh diameter | 50um |
| Nominal spacing between lines | 75um |
| Talc | 2kg/m3 |
| Vibration time | 99 minutes 59 seconds |
| Timer | 99 hours 59 minutes |
| Specimen power socket | Dust-proof socket AC220V 16A |
| Controller | Adopt imported PLC program to control the LCD, and use all Chinese to display Operating Time, etc.; |
| Vacuum system | Equipped with pressure gauge, air filtrate, pressure regulating triplet, connecting pipe (Vacuumpump is additional, please explain when ordering) |
| Circulating Fan | Enclosed alloy low noise motor, multi-leaf centrifugal fan; |
| Dust heating system | Stainless steel mica sheet heating sleeve |
| Power | AC380V ± 10% 50Hz three-phase five-wire system |
| safety protection | Leakage, short circuit, over temperature, motor overheating, over current protection |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. If the instrument and equipment are not artificially caused by product quality problems, the manufacturer provides 1 year free warranty service;
2. During the warranty period, the manufacturer will arrange to deal with the equipment failure caused by the quality of the product itself within 48 hours after receiving the notice;
3. Outside the warranty period, the manufacturer will maintain it free of charge, and only charge the cost of parts and the cost of the engineer's on-site travel;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/27001/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
