UNI-T UTi160H infrared thermal imagery instrument, lens 5mm

UNI-T UTi160H infrared thermal imagery instrument has surface temperature measurement and real-time thermal image function, the lens diameter is 5mm, UTi160H infrared thermal imagery instrument with PIP picture-in-picture function and MIF multi-Light spectrum image fusion algorithm.
Model：
Contact
Details SPEC CAT

UNI-T UTi160H Infrared thermal imagery instrumentSPEC

UNI-T UTi160H Infrared thermal imagery instrumentDetails

UNI-T UTi160H Infrared thermal imagery instrumentPacking list

SKU
NB027135
lens
5mm
Spatial resolution
3.30mrad
Focus method
fixed focus
resolution
160×120
Field of view
30°×23°
Thermal Sensitivity
60mk
frame rate
50Hz
Electronic amplification
×2，×4
Temperature Measurement Range
-20~650℃
Accuracy
±2℃/±2%
temperature coefficient
+/- 0.1/℃ or +/- 0.1%/℃ any larger
Visible light resolution
640×480
emissivity
Emissivity adjustable (0.01-1), default 0.95
reflectance
Reflectance correction (background temperature adjustable)
Color matching board
6 kinds
non-uniformity correction
√
Manual luminance contrast ratio
√
Automatic luminance contrast ratio
√
High and low temperature tracking
√
High and low temperature alarm
√
MIP
√
PIP
√
mobile app
√
Computer real-time transmission
√
Display Accuracy
0.1℃/0.18℉
Protection level
IP43
Power Battery
3.7V 4200mAh lithium battery UN38.3 certification
Battery life
Continuous work for more than or equal to 4 hours
UTi160H
Infrared thermal imagery instrument
UNI-T UTi160H infrared thermal imagery instrument, lens 5mm Picture

Introduction

The UTi160H is a thermal imaging camera that combines surface temperature measurement and real-time thermal imagery, which requires each component to be measured one by one, but not with a thermal imager, where potential problems are clearly displayed on the screen. It has a MIF multispectral image fusion algorithm, which closely combines visible light with infrared thermal imaging camera. The full range of 50Hz frame rate displays ensures smooth and natural images, helping users diagnose hard-to-reach parts in any environment. Full-featured infrared analysis software enables more detailed analysis of images and automatically creates convincing inspection reports so you can make critical decisions faster.

Features

  • 5mm lens size

  • 3.30mrad spatial resolution

  • 160×120 IR resolution

  • 30°×23° field of view

  • Fixed focus design

  • It has a visible image display

  • and a combination of PIP picture-in-picture function and MIF multispectral image fusion algorithm

  • Mobile APP function

UTi160H Infrared Thermal Imager Display
