Specifications
| Temperature range | 100~1200℃ |
| Fluctuation | ±2℃ |
| Temperature Resolution | 1℃ |
| Furnace size | 200*300*500mm |
| Heating rate | 1~30℃/min |
| Input power | 12kw |
| Power | 380V 50Hz |
| Exterior material | The outer box shell is made of good cold plate, treated with phosphoric acid film salt, and then sprayed at high temperature. Color is computer gray |
| Furnace material | Pottery and porcelain fibres |
| Thermal insulation method | Thermal insulation brick and thermal insulation cotton |
| temperature measuring port | Thermocouple enters from above the back of the furnace |
| Heating Elements | resistance wire |
| Thermocouple | K Indexing Nickel Chromium - Nickel Silicon Thermocouple |
| Temperature control instrument | PID adjustment, display Accuracy 1 ℃ |
| Complete sets of electrical appliances | Brand contactor, cooling fan, solid state relay |
| time system | Operating Time can be set, thermostatic time arrives, automatic shutdown |
| Over temperature protection | Built-in secondary over-temperature protection device, double safety. over-temperature alarm, over-temperature interruption |
| Run function | Full range programmable setting, 30 program settings, automatic control of temperature rise thermostatic |
Packing list
host x1, instruction manual x1, certificate x1, warranty card x1.
After-sales instructions
Warranty days: 365 days
Non-artificially caused product quality problems, the manufacturer provides 1 year free warranty service.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/27306/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
