Specifications
| range | 10N.m、102kgf.cm、88.5lbf.in |
| resolution | 0.01N.m、0.1kgf.cm、0.001lbf.in |
| Accuracy class | Level 0.5 |
| Indication relative error | ≤±0.5% |
| Dimension | 230*130*70mm |
| Net Weight | 2.6kg |
| unit | N.m、kgf.cm、lbf.in |
| Power Supply | Lithium Battery: 3.7V/1000mAh |
| Charger | AC Input：220V/50HZ、DC Output：5V/1A |
| Operating temperature | 0℃-40℃ |
| Storage temperature | -20℃-70℃ |
| Relative Humidity | 15%-80% |
| Operating Environment | No vibration and corrosion medium around |
Packing list
Host x1, Test Head Accessories x1 Set, Charger x1, Software x1, Communication Cable x1, Signal Cable x1, Encasement Box x1, Manual x1, Certificate of Conformity (Warranty Policy) x1
After-sales instructions
Warranty days: 365 days
1. Warranty: one year
2. Within one month after purchase, if there is a product quality problem under normal use and no damage to the appearance, the product of the same model and specification can be replaced with the invoice, valid warranty card and complete packaging;
3. There is no warranty for man-made failure or customer disassembly;
4. Products beyond the warranty period can be repaired by the original factory.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/27355/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
