Specifications
| Measurement principle | Magnetic induction + eddy current |
| Measuring range | 0 ~ 1250µm |
| margin of error | ±3% |
| resolution | 0.1mm | 1mm |
| Minimum radius of curvature | F: convex 1.5mm/concave 25mm; N: convex 3mm/concave 50mm |
| thinnest matrix | 0.3mm |
| probe | F and NF split probes |
| Power | 4 * AAA battery |
| Calibrated Certificate | without |
| Language | Chinese |
| Display screen | LCD |
| supporting software | without |
| Total Weight | 120G (without battery) |
| Complete-built unit size | 126*65*27mm |
| Minimum measurement surface | F6mm |
| Unit display | μm/mils |
| Voltage prompt | Low Voltage prompt |
| Operating Temperature | 0~40℃ |
| Relative Humidity | 10~90%RH |
Packing list
host x1, probe (iron-based/eddy current) x1 each, reference block (iron-based/aluminum-based) CTG-BS x1 each, calibrated diaphragm CTG-CFx4, portable box x1, manual x1
After-sales instructions
Warranty days: 730 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/274/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
