Specifications
| Measured value | 100N |
| Load Graduation | 0.02N |
| Displacement scale stroke | 100mm |
| platen diameter | Ф78.5mm |
| Measurable maximum free length of spring | 100mm |
| effective travel | 125mm |
| Maximum pressure space | 245mm |
| Maximum space for pulling | 155mm |
| Dimension | 300*225*610 |
| Net Weight | 18kg |
| Precision | ±0.5% |
Packing list
Host x1, micro printer x1, communication cable x1, software CD x1, Encasement box x1, manual x1, certificate of conformity (warranty) x1
After-sales instructions
Warranty days: 365 days
1. Warranty: one year
2. Within one month after purchase, if there is a product quality problem under normal use and no damage to the appearance, the product of the same model and specification can be replaced with the invoice, valid warranty card and complete packaging;
3. There is no warranty for man-made failure or customer disassembly;
4. Products beyond the warranty period can be repaired by the original factory.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/27409/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
