Specifications
| Measured value | 1000N 100kg 220lb |
| effective travel | 385mm |
| Displacement Graduation | 0.1mm |
| Movement displacement error | 0.1mm |
| speed | 10-800mm/min |
| Speed Graduation | 0.2mm/min |
| Speed setting error | 10-200mm/min ±1mm 200-800mm/min ±0.5% |
| loading method | electric |
| Power Supply | AC 220V 50/60HZ |
| Dimension | 360*250*990mm |
| Weight | 39.5kg |
Packing list
host x1, power cord x1, fixture x2, manual x1, certificate of conformity (warranty) x1
After-sales instructions
Warranty days: 365 days
1. Warranty: one year
2. Within one month after purchase, if there is a product quality problem under normal use and no damage to the appearance, the product of the same model and specification can be replaced with the invoice, valid warranty card and complete packaging;
3. There is no warranty for man-made failure or customer disassembly;
4. Products beyond the warranty period can be repaired by the original factory.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/27419/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
