Specifications
| Operation mode | Touch screen operation |
| Display | LCD display |
| Analysis | 1/20000 |
| unit conversion | Kgf/cm2, psi (lbf/in2), kpa (three units are converted to each other) |
| Error of indication | ±0.5%FS |
| Indication variability | ≤0.5% |
| Clamping Force | >690Kpa |
| System sealing | 1Min pressure drop < 10% Pmax |
| Resolution | 1kPa |
| Displacement | (0.02~0.3) m3 /min |
| air source pressure | ( 0.6~0.7) Mpa |
| Weight | About 50Kg |
| Hydraulic oil | Glycerin 85%, distillation water 15% |
| Clamp ring diameter | Upper ring: high Voltage type Should be 31.50mm Lower ring: high Voltage type Should be 31.50mm |
| Dimensions | 410*430*560mm |
| Power supply Voltage | AC220V , 50Hz 120W |
| Measurement range | 250~5600kPa |
| Oil delivery speed | 170±15mL/min |
Packing list
whole machine X1, operation manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
