Specifications
| Combustion size | φ 12mm +/- 0.5mm, about 100mm long |
| Combustion angle | 45° |
| flame height | 20Mm +/- 2mm to 175mm +/- 1mm adjustable |
| Flame time | 0~999.9S +/- 0.1s adjustable |
| holding time | 0-999.9S +/- 0.1s, automatic recording, manual pause |
| Combustion gas | 98% propane gas (in general, liquefied petroleum gas can be used instead) |
| Flow rate pressure | With dual flow and pressure gauges (gas and air) |
| Glowing wire temperature | 0~1000℃ |
| Flame temperature requirements | The time to rise from 100 ℃ +/- 2 ℃ to 700 ℃ +/- 3 ℃ is within 45 seconds +/- 5 seconds |
| Thermocouple | φ 0.5mm Armored (Type K) Thermocouple |
| experimental background | Black Background |
| Test process | Test program automatic control, no exhaust fan |
| reference standard | GB/T18380.1、 IEC60332-1 、 GB/T5169 |
| Timer | 0~99.99S/m/h |
| Ignition method | High Voltage electronic ignition, convenient and stable |
| Power supply Voltage | AC 220V/50H |
Packing list
whole machine X1, operation manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/27675/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
