Specifications
| Needle combustion device | Stainless steel, inner hole φ 0.5 +/- 0.1mm, outer diameter ≤ φ 0.9mm, length ≥ 35mm |
| Combustion angle | Vertical (when adjusting and measuring flame height) and tilted 45 ° (when testing) |
| Ignition paving layer | 10Mm thick white pine board, covered with 12g /m2~ 30g/m2 standard silk paper, 200mm +/- 5mm from the flame application |
| Combustion gas | 95% butane gas (base gas), propane gas can also be used |
| Gas flame temperature layer | 100 ℃ +/- 2 ℃~ 700 ℃ +/- 3 ℃ (room temperature~ 999 ℃), 23.5s +/- 1.0s (1s~ 999.9s) |
| flame height | 12Mm +/- 1mm (adjustable) |
| Flame time | 5S, 10s, 20s, 30s, 60s, 120s~ 1 + 0 s (1s~ 999.9s digital display can be preset) |
| holding time | 1S~ 999.9s (digital display, can be manually paused to hold digital display) |
| Test space | ≥ 0.5m3, background black or 1m3 |
| Thermocouple | Equipped with K-type 0.5mm insulated armored couple, the armored sleeve is heat-resistant to 1100 ℃ |
| Exhaust hole size | 100mm |
| Test Power Supply | 220V 0.5kVA |
Packing list
whole machine X1, operation manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
