Specifications
| Glowing wire temperature | 500~1000 ℃ +/- 2 ℃ continuously adjustable |
| Flame time | 0~999.9S +/- 0.1s adjustable (generally selected as 30s) |
| ignition time | 0-999.9S +/- 0.1s, automatic recording, manual pause |
| afterflame time | 0-999.9S +/- 0.1s, automatic recording, manual pause |
| Thermocouple | φ 0.5mm imported armoured (K type) Thermocouple |
| Glowing wire | φ 4mm nickel-chrome wire |
| Burning depth | 7mm±0.5mm |
| sample pressure | 1N±0.2N |
| Test speed | 14mm/s |
| experimental background | Black Background |
| Test process | Test program automatic control, independent ventilation |
| reference standard | GB/T5169.10-2006 , IEC60695-2-10：2000，UL746A |
| Studio Volume | 0.5m3 |
| Equipment external Dimensions | 1000Mm wide × 650mm deep × 1300mm high |
Packing list
whole machine X1, operation manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/27679/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
