Specifications
| Combustion chamber size | Width x Height x Depth: 385x 360x 204mm |
| Ventilation hole/ventilating slot size | There are 10 ventilation holes with a diameter of 19mm at the bottom, and there are 13mm wide ventilating grooves around the four walls near the top |
| test bracket | Made of two U-shaped corrosion-resistant metal steel plates, |
| Test bracket size | Length x width 361x100mm |
| Flame time | 0~99.99/S/M/H can be set arbitrarily |
| afterflame time | 0~99.99/S/M/H can be set arbitrarily |
| Nozzle inner diameter | 9.5Mm with flame adjustment function |
| flame height | 38mm |
| gas source | Natural gas or gas |
| Metal comb | Length: greater than 110mm, each 25mm contains 7 to 8 smooth teeth |
| steel ruler | Length 400mm, Accuracy 1.0mm |
| thermometer | Range greater than 150 ℃ with Accuracy of +/- 1 ℃ |
| Power supply Voltage | 220V 50HZ |
Packing list
whole machine X1, operation manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/27681/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
