Specifications
| test station | Can test two samples at the same time, each can do six buttons, can be set 1-2-3 - 4-5-6 cycle test |
| Control mode | Touch screen setting input direct action, simple and convenient action |
| mode of action | The cylinder drives the probe to reciprocate up and down |
| Test speed | 10~60 times/minute, manually adjustable |
| Test phone thickness | 10~50Mm can be |
| Mobile phone clamping fixture | Clamp both sides of the lower cover |
| Height adjustment | Manual direct adjustable |
| Dimension | 1200×450×520mm |
| Power supply Voltage | 220V |
| Weight | About 55kg |
Packing list
whole machine X1, operation manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/27702/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
