Specifications
| Test load type | 5Kgf (standard), 2kgf, 500gf |
| Minimum display load | 0.01gf |
| Maximum test stroke | 100mm |
| Minimum Display Trip | 0.001mm |
| Test speed range | 0-200mm／min |
| Unit switch | N，Lb，kgf，gf |
| Transmission mechanism | Ball screw |
| Drive motor | AC servo motor |
| Dimension | 300*270*500mm |
| Weight | 25kg |
| Power supply Voltage | AC220V 5A or specified |
Packing list
whole machine X1, operation manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/27703/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
