Xiangmin XM-MT006 Martindale Wear resistance instrument (six stations)
The number of grinding heads is 6, the friction Frequency is 50-2r/min, the relative movement speed of the holder and the grinding table, the counting mode can be set 0-999900 times, the automatic shutdown after the measurement is completed, the whole machine weight is 80Kg, which meets the standards ISO5470, BS3424/5690, ISO12945, 12947, JIS L1096, IWSTM112/196, ASTM4966/4970.GB//T4802, 13775, the holder is 200 +/- 1g, and the furniture decoration sample weight is 594 +/- 2g.
Model：
XM-MT006
Similar products
xiangmin XM-MT006 Martindale Wear resistance instrument (six stations)SPEC
xiangmin XM-MT006 Martindale Wear resistance instrument (six stations)Details
xiangmin XM-MT006 Martindale Wear resistance instrument (six stations)Packing list
- SKU
- NB027713
- Number of grinding heads
- 6 digits
- Friction Frequency
- 50-2R/min Relative movement speed between gripper and mill
- Counting method
- 0-999900 times can be set, and it will automatically stop after the measurement is completed.
- Machine Weight
- 80Kg
- Standards
- ISO5470, BS3424/5690, ISO12945, 12947, JIS L1096, IWSTM112/196, ASTM4966/4970.GB//T4802,13775
- gripper
- 200±1g
- Furniture decoration sample Weight
- 594±2g
- Clothing sample Weight
- 395±2g
- Stainless steel butterfly sheet
- 260±1g
- Effective friction diameter of grinding block
- A type, 200g (1.96N) friction head, 28.8 -0.084mm /B type 155g (1.52N) friction head, 90 -0.10mm
- Sampling hammer quality
- 2385±10g
XM-MT006
Martindale Wear resistance instrument (six stations)
The number of grinding heads is 6, the friction Frequency is 50-2r/min, the relative movement speed of the holder and the grinding table, the counting mode can be set 0-999900 times, the automatic shutdown after the measurement is completed, the whole machine weight is 80Kg, which meets the standards ISO5470, BS3424/5690, ISO12945, 12947, JIS L1096, IWSTM112/196, ASTM4966/4970.GB//T4802, 13775, the holder is 200 +/- 1g, and the furniture decoration sample weight is 594 +/- 2g.
FAQ
QMeet ISO7784-3 Martindale wear-resistant instrument
A
XM-MT006 Martindale wear-resistant instrument, please refer to it.
