Specifications
| Measurement principle | Magnetic Induction |
| Measurement range | 10~3000μm |
| margin of error | ±2μm/2% |
| Resolution | 0.1μm |
| Minimum measurement surface | 10x10mm |
| Minimum radius of curvature | Convex: 5mm; Concave "50mm" |
| thinnest substrate | 0.5mm |
| probe | built-in |
| Probe material | Carbide cutter head |
| Calibrated mode | Factory zero calibrated |
| Unit display | μm |
| statistical function | Measurement times, MAX Maximum, MIN Minimum, Average, Standard deviation |
| Power Supply | 2 AAA batteries |
| Standards | DIN、ISO、ASTM、BS |
| Display screen | Backlight, 4 alphanumeric, height 8mm |
| Operating temperature | 0℃~+50℃ |
| Protection level | IP52 |
| supporting software | Yes. |
| Machine Weight | 90G (including battery) |
| Machine size | 110*50*25mm |
| Probe contact temperature | -15~60℃ |
Packing list
host x1, test piece 100umx1, zero standard piece x1, material package x1, rubber protective cover x1, battery x2, user manual x1.
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
3. The probe is guaranteed for three months.
