Specifications
| maximum temperature | 1500℃ |
| Temperature range | 1450℃ |
| Heating Elements | 1540 ℃ high purity silicon carbide rod |
| Furnace material | Aluminum oxide fiber |
| Furnace Volume | 4.1L |
| Temperature control Accuracy | ±1℃ |
| Furnace size | 160*160*160mm |
| Dimension | 460*730*530mm |
| Weight | 70kg |
| Heating power | 3KW |
| component specification | Carbon U/12/120 (130)/180/40 4 pieces |
| Furnace mode | Side opening |
| maximum temperature | 1700℃ |
| Heating zone | single temperature zone |
| Linear dispersion setting | 15 temperature Linear dispersions can be pre-stored, and each Linear dispersion can be set for 30 "time-temperature Linear dispersion" |
| Operating interface | Chinese and English interchangeable graphical interface, true color touch screen input, fool-style human-machine dialogue mode |
| Linear dispersion setting | Real-time monitoring, dynamic real display "Time-temperature Linear dispersion" |
| Temperature measuring element | Platinum Rhodium S Thermocouple |
| protection settings | Over-temperature alarm, over-current protection, couple break prompt |
| Electrical certification | CE certification |
| Power supply Voltage | 220V/50Hz 3KW (thermostatic Power about 2KW) |
Packing list
Host x1, door plug x1, burning board x1, Protective Gloves x1, crucibletong x1, manual x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/27727/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
