Specifications
| Maximum load | 200N/20Kg/44lb |
| effective travel | 225mm |
| Displacement Graduation | 0.1mm |
| Movement displacement error | 0.1mm |
| speed | 10-800mm/min |
| Speed Graduation | 0.3mm/min |
| Speed setting error | 10-200mm/min ±1mm 200-800mm/min ±0.5% |
| loading method | electric |
| Power Supply | AC 220V 50/60HZ |
| Dimension | 405mm*270mm*1220mm |
| Weight | About 56kg |
Packing list
power cord x1, product manual x1, certificate of conformity warranty card x1, fixture x2
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/27903/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
