Specifications
| Light source | A Light source (2856K)/C Light source (6774K) |
| Measurement range | Light transmitance 0% -100.00%; Haze 0% -100.00% (0% -30.00% absolute measurement); (30.01% -100.00% relative pair measurement) |
| Minimum indication | Light transmitance 0.01%, haze 0.01% |
| An indication of light transmitance error | +/- within 1% (standard neutral gray film ）； +/- within 2% (standard haze film) |
| Haze indication relative error | +/- 5% or less |
| Repeatability | Light transmitter ≤ 0.5%; haze ≤ 0.2 |
| Sample window size | Entry window Should 23mm Exit window Should 21mm |
| Display | 7-Inch color LCD screen |
| communication interface | USB |
| data storage | 2000 groups |
| Power Supply | 220V±22V 50Hz±1 Hz |
| Dimension | 710*270*280mm |
| Net Weight of instrument | 15kg |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/27961/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
