Specifications
| Light source | C Light source (6774K) |
| Measurement range | Light transmitter 0-100%; Haze 0-99% (0-30% absolute measurement); (30.1-99% relative measurement) |
| Minimum indication | Light transmitance 0.1%, haze 0.01% |
| error of indication | Light transmitter error of indication ： +/- within 1% (standard neutral gray sheet ）； +/- 2% (standard haze sheet); haze indication relative error ： +/- 5% |
| Repeatability | Light transmitter Repeatability: ≤ 0.5%; Haze Repeatability: ≤ 0.2 |
| Sample window size | Entry window Should 23mm Exit window Should 21mm |
| Display | digital tube |
| communication interface | USB |
| Power Supply | 220V±22V，50Hz±1Hz |
| Dimension | 710*270*280mm |
| Net Weight of instrument | 19kg |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/27963/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
