Specifications
| Light source | LED |
| Measurement range | Red: R 0.1~ 80; Yellow: Y 0.1~ 80; Blue: B 0.1~ 50; Neutral gray: N0.1~ 4 (LOVIBOND unit) |
| error of indication | ≤5% |
| Indication Repeatability | ≤±0.2 |
| Display range | 0℃~50℃ |
| data storage | 1000 sets |
| Display mode | 7-Inch color LCD touch screen |
| Communication interface | RS232, USB, USB flash drive |
| Printer model | CK NT-T24S (optional) |
| Colorimetric dish size | 10mm×20mm×40mm；25.4mm×20mm×40mm；133.4×20mm×40mm |
| Power Supply | 220V~ 240V Frequency 50Hz +/- 1Hz |
| Dimension | 368mm×270mm×150mm |
| Net Weight | 4.5kg |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/27966/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
