Specifications
| Lighting method | Halogen lamp 6V, 10W |
| receiving element | Photocells, photovoltaic cells |
| Measurement range | 0.000~50.00、50.01~200.0、200.1~2000、2001~4000NTU |
| Display mode | LCD touch screen digital display |
| resolution | 0.001 |
| error of indication | ≤±6% |
| Zero drift | ≤±0.3%FS |
| Indication Stability | ≤±1％FS |
| Repeatability | ±0.5%F.S |
| sample bottle | Φ25mm×95mm |
| sample Capacity | 30ml-40ml |
| store data | 1000 sets |
| Calibration Point | 7 point |
| Communication interface | USB/U disk |
| printer | RD-TH32-SC (optional) |
| Power supply Voltage | 220V±22V 50Hz±1Hz |
| Dimension | 358*323*160mm |
| Net Weight of instrument | 6kg |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/27971/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
