INESA WGZ-500B Portable Turbidity Meter 500NTU

SE
Adopt LED Infrared source and scatter-transmission light measurement principle, with automatic range switching and multi-point calibrating function, support NTU, FTU and other turbidity units, suitable for water quality and transparent liquid analysis. It has 2000 sets of data storage, USB communication interface, data upload and printing functions
Model：
Certificate
Contact
Details SPEC VIDEO CAT

INESA WGZ-500B Portable Turbidity MeterSPEC

INESA WGZ-500B Portable Turbidity MeterDetails

INESA WGZ-500B Portable Turbidity MeterPacking list

SKU
NB027981
Light source/wavelength
LED light/860nm wavelength
Unit switch
NTU, FTU, EBC, ASBC turbidity units
Measurement range
0.000~20.00NTU、20.01~200.0NTU、200.1~500.0NTU
Display mode
liquid crystal display
resolution
0.001
error of indication
≤±6%
Zero drift
≤±0.5%FS
Indication Stability
≤±0.5%FS
Repeatability
±0.5%F.S
data storage
2000 groups
Communication interface
USB
printer
Needle printer CK NT-T24S (optional)
Calibration Point
5 point
sample bottle
Ф25mm×65mm
sample Capacity
20ml-30ml
Power supply Voltage
4 AA alkaline batteries, 5V/USB Power Supply
Dimension
220*95*85mm
Net Weight of instrument
0.65kg
WGZ-500B
Portable Turbidity Meter
Adopt LED Infrared source and scatter-transmission light measurement principle, with automatic range switching and multi-point calibrating function, support NTU, FTU and other turbidity units, suitable for water quality and transparent liquid analysis. It has 2000 sets of data storage, USB communication interface, data upload and printing functions
INESA WGZ-500B Portable Turbidity Meter 500NTU Picture

A Turbidity Meter is an instrument used to measure the degree of scattering and attenuation of light produced by insoluble particulate matter suspended in water (or transparent liquid) and to quantitatively characterize the content of these suspended particulate matter. It is widely used in water plants, food, chemical industry, power plants, metallurgy, environmental protection, beverage, winemaking, industry and other departments, and is a commonly used laboratory instrument.

Features

Adopt microcomputer technology, low-power configuration, touch keyboard, with backlit LCD screen;

LED infrared light source, battery powered and USB powered, with automatic power-off power saving function

Scattered-transmitted light measurement principle, ratio calibration

Automatic range switching, support multi-point calibration

With average measurement function; It can store 2000 sets of test data, and the data can be saved, printed and uploaded

The setting function of time, date, sample name and user name is in line with GLP specifications and ISO7027 industry standards

USB communication interface, support to connect to PC for data upload


Serial models

Instrument modelWGZ-20BWGZ-50BWGZ-100BWGZ-200BWGZ-500BWGZ-1000BWGZ-2000B
Light source/wavelengthLED lamp/860nm wavelength
Unit switchingNTU, FTU, EBC, ASBC turbidity units
Measuring range0.000-20.000.000-20.00

0.000-20.0

020.01-100.0

0.000-20.00

20.01-200.0

0.000-20.00

20.01-200.0

200.1-500.0

0.000-20.00

20.01-200.0

0.000-20.00

20.01-200.0

20.01-50.00200.1-1000200.1-2000
How it is displayedLiquid crystal display
Minimum reading0.001
Indication error≤±6%
Zero drift≤±0.5%FS
Stability of the indication≤±0.5%FS
Instrument repeatability≤0.5%
Data Storage2000 groups
Communication interfaceUSB
printerDot matrix printer CKNT-T24S (optional)
Calibration method2 points3 points4 points4 points5 points6 points7 points
VialsФ25mm×65mm
Sample capacity20ml-30ml
power supply4 x AA alkaline batteries, 5V/USB power supply
Instrument size220mm×95mm×85mm
Net weight of the instrument0.65kg


FAQ
QDo you have the portable turbidity meter required by the ISO15715 standard?
A This WGZ-500B portable turbidity meter will do.
