Specifications
| Measurement range | 0.1~3000μm |
| Total Magnification | 8000 times |
| Maximum resolution | 0.1 micron/pixel |
| Repeatability | Error ≤ +/- 1% |
| Automatic segmentation speed | ≤ 1 second |
| Digital Camera (CCD) | 5 million pixels |
| data storage | All-in-one machine (128G solid-state drive, 15-inch monitor) |
| communication interface | USB/network cable/wireless network |
| Operating system | Windows 98/XP/7/8/10 |
| Power Supply | AC220V ±10％ 200W |
| Dimension | 625*420*435mm |
| Net Weight of instrument | 25kg |
Packing list
Host X1, domestic (CN) Microscope x1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/28008/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
