Specifications
| Maximum test force | 20KN |
| High Precision Sensors Precision | ±0.5% |
| Load Accuracy | ± 1% resolution 1/20000 yards |
| Speed Accuracy | ±0.5% |
| Test speed range | 0.05~ 500mm/min (above 1T: 1~ 250mm/min) or set according to user requirements |
| displacement resolution | 0.1mm |
| Large Measurement range | Marking line - 1000mm (optional) |
| Effective travel of moving beam | 1000mm can make different stretching spaces according to user requirements |
| Displacement error of indication | ±0.5% |
| Power | AC220V 50Hz |
| Dimensions | 700*380*2150mm |
| Net Weight | 320K |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/28141/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
