Specifications
| Maximum test force | 20KN |
| Effective detection range | 1% of the maximum experimental force |
| Load resolution | 1N |
| Load measurement Accuracy | Within ± 1% of the indication |
| Test speed | 1mm-50mm/min |
| Test space range | 150mm |
| Specimen range | 1300×600mm |
| Drive mode | Servo motor drive |
| Power | Single-phase AC 220V/50Hz, motor power 550 W |
| Dimensions | 1400*1200*1500mm |
| Weight | 220KG |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/28144/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
