Specifications
| load cell | 1000N |
| Force unit | kgf,N,Lbf,gf,kN |
| unit of intensity | MPA,KPA,kgf/mm2,N/mm2 |
| force resolution | 1/10000 |
| Force value Accuracy | ≤1％ |
| force magnification | stepless |
| displacement resolution | 1/1000 |
| Displacement Accuracy | ≤1％ |
| Test speed range | 0.01~500mm/min |
| Walking space | 600Mm (excluding gripper, special test space can also be customized according to customer needs) |
| test width | 400Mm (special test width can also be customized according to customer needs) |
| Power Supply | ∮220V 50HZ |
| power | 400W |
| Dimensions | About 500 * 450 * 1450mm |
| Machine Weight | About 100KG |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
【After-sales service】
1. One year warranty
2. Lifetime maintenance
3. Damage caused by human factors, or damage caused by improper use, is not covered by the warranty
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/28212/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
