Specifications
| Capacity | 2T |
| control mode | Microcomputer control |
| Analysis | 1/100000 |
| error of indication | ±1% |
| Plate size | 800*800mm |
| Analysis | 1/100000 |
| Sampling frequency | 400 times/second |
| Pressurization speed | 5~100mm/min |
| Speed Accuracy | Indication +/- 1% |
| force channel | 2 |
| Voltage output | 0~6V |
| output control | Inverter motor stepless speed regulation |
| printout | Automatically print reports, (Chinese) print (maximum power, average value, free point value, breakpoint ratio, date) |
| unit switching | N、kgf、Lbf |
| single test | Manual 10-point statistics, and automatically calculate the average value, maximum pressure resistance value, can store up to 5 groups |
| Overload protection function | Configurable |
| Power Supply | AC220V 5A |
| Weight | About 500KG |
| power | 1.5kw |
| Working Travel | 1000mm |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
【After-sales service】
1. One year warranty
2. Lifetime maintenance
3. Damage caused by human factors, or damage caused by improper use, is not covered by the warranty
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/28216/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
