Specifications
| indentation rate | 0.01~0.70mm/s |
| Dimensions | 390*355*450mm |
| Total Mass | Approx. 29kg |
| Stroke length | 0~12mm |
| Speed Accuracy | +/- 1% of the set speed |
| Stroke length Accuracy | +/- 0.01 mm or 0.2%, whichever is greater |
| Power Consumption | ≤90w |
| test panel width | ≤105mm |
| Maximum panel thickness - steel | 0.8mm |
| Maximum speed of steel panel | 0.6mm/s |
| Maximum Panel Thickness - Aluminum | 1.2mm |
| Aluminum panel maximum speed | 0.7mm/s |
| Display | Full color 480 x 272 pixel TFT display |
| security | Emergency button with integrated audible alarm |
Packing list
Host X1, Encasement box X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/28218/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
