Specifications
| Measurement principle | Magnetic Induction + eddy Current (depending on probe) |
| Measurement range | Determined by the probe |
| Calibrated mode | Zero calibrate, 1 point calibrate, 2 point calibrate, independent (independent adjustment) calibrate, ISO19840 zero point offset, ISO19840 2 point, SSPC PA2 zero point offset, SSPC PA2 2 point, AS 3894.3 Switzerland, SIS 184160 Australia |
| Measurement mode | Manual selection of substrate, automatic selection of substrate, double substrate combined measurement, continuous measurement, button trigger measurement |
| Unit display | µm/mil conversion |
| Interface | USB port |
| Data storage | 2000000 measurement readings (100 for storage tasks) |
| Power Supply | 2xAA alkaline dry battery/rechargeable battery/USB |
| Standards | DIN EN ISO 2808, DIN 50981, DIN 50984, ISO 2178, BS 5411 (3 & 11), BS 3900-C5, ASTM B 499, ISO 2360, ASTM D 1400, ASTM D 1186, ASTM D 7091 |
| Display screen | 2.4-Inch IPS-LCD color liquid crystal, 600 lumens, 70 ° Viewing Angle |
| Operating temperature | -20 ℃ -70 ℃ |
| Battery life | When the battery is not in use, 50% Capacity > 1 year, 60,000 times |
| Protection level | IP64 |
| Machine Weight | 175 g |
| Machine size | 155*65*44 mm |
| Storage temperature | -20~70℃ |
| Probe support | Trogramid® |
| Body hard material | PA12 GF30 |
| Body soft material | TPE |
| system clock | CR1220 |
| Battery life | > 2 years |
| Pin code protection | Yes. |
| Calibrated value memory | 10 groups |
Packing list
9500 host X1
After-sales instructions
Warranty days: 365 days
If the product quality is not caused by man-made, the manufacturer provides 1 year free warranty.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/28235/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
