Specifications
| Spray hole diameter | 12.5mm |
| Flow rate | 100±5L/min |
| Jet water pressure | 80~100Kpa, adjustable water pressure |
| Maximum load-bearing of the turntable | 50kg |
| Turntable lifting height | 400-750mm |
| Rotation speed of turntable | 1-5R/min (accurately adjustable) |
| Turntable rotation method | Forward/reverse alternation |
| Flow rate adjustment | Flow rate adjustment with adjustment panel |
| test time | 0-999min |
| Total Weight of equipment | About 250kg |
| Water spray distance | 2.5 meters (distance between the nozzle and the center of the turntable) |
| Spray gun fixing method | Mechanical fixation |
| turntable diameter | 600mm |
| Protection device | Leakage, water shortage, short circuit |
| Inner box size | 1000*1000*1000mm |
| Dimension | About 1200 × 3500 × 1850mm |
| Turntable size | 500Mm circular turntable |
| Round turntable | Round stainless steel rod welded |
| Rotation speed of turntable | 1~ 5R/min adjustable |
| water storage tank | SUS304 stainless steel plate bending |
| nozzle | Processed by SUS304 |
| water pressure control | Flow rate meter |
| water pump | Special stainless steel centrifugal pump |
