Specifications
| Measuring range | 0~99999 times |
| folding angle | 135±2° |
| folding speed | 175±10CPM |
| spring tension | 4.9~14.7N |
| Tension change | The tension change caused by the swirl/spin eccentricity of the folding collet is not more than 0.343N |
| Folding head width | 19±1mm |
| Folding radius | 0.38±0.02mm |
| Folding mouth gap distance | 0.25mm/0.5mm/0.75mm/1.00mm |
| Standard Weight | 4.9N、9.8N |
| Human Machine Interface | 3.2 in 320 * 240 dot matrix liquid crystal display, real-time display of folding changes |
| printout | Modular integrated thermal printer |
| Operating Environment | Temperature (0~35) ℃, humidity < 85% |
| Dimensions | 330*350*450mm |
| Weight | 35kg |
| Power | AC220V，50Hz |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/28454/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
