Specifications
| Power supply Voltage | AC220V±10% 2A 50Hz |
| number of double folds | 0~99999 times |
| folding logarithm | 0~4.99 |
| folding angle | 135±2° |
| folding speed | 175±10CPM |
| Spring tension | 4.91~14.72N |
| crease radius | 0.38±0.02mm |
| Folding mouth seam distance | 0.25mm/0.5mm/0.75mm/1.00mm |
| Human Machine Interface | 4.3 "Color touchscreen |
| printout | modular integrated thermal printer |
| Operating Environment | Indoor temperature (20 +/- 10) ℃; Relative Humidity < 85% |
| Dimensions | 240*320*560mm |
| Weight | About 23.2kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/28480/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
