Specifications
| Power supply Voltage | AC （100~240）V 2A 50/60Hz； |
| Error of indication | ±1% |
| Indication variability | ≤1% |
| Measurement range | 20~10000mN |
| Resolution | 0.1mN |
| bending length | (50±0.5)mm；(10±0.2)mm |
| bending angle | (15±0.3)º；(90±0.5)º |
| Specimen size | 70*38mm |
| Specimen size | 36*38mm |
| Display | 4.3 "Color touchscreen |
| printout | Thermal printer, printing high-speed mute |
| Communication interface | RS232 (standard)/USB (optional) |
| Environmental conditions | Indoor temperature (20 +/- 10) ℃, Relative Humidity < 85% |
| Dimensions | 250*170*210mm |
| Weight | About 8kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/28483/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
