Specifications
| Power Supply | AC 220V±10% 2A 50Hz |
| Measurement range | file A |
| Resolution | 0.1mN |
| Human Machine Interface | 4.3 "Color touchscreen |
| Error of indication | ±1% |
| Tear arm | 104±1mm |
| Paper surface size | 25*15mm |
| tearing initial angle | 27.5±0.5° |
| Distance between clamps | 2.8±0.3mm |
| Specimen incision length | 20±0.5mm |
| communication output | RS232 (std.)/USB (optional) |
| printout | Thermal printer |
| Dimensions | 410*320*600mm |
| Weight | About 30kg |
| Indication variability | ±1% |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/28485/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
