Specifications
| Power supply Voltage | AC 220V 2A 50Hz |
| Measurement range | 0.1~50N |
| Error of indication | ±1% |
| Indication variability | ≤1% |
| Resolution | 0.001N |
| Oil delivery speed | 125±5mm/min |
| concentric ring inner diameter | （50±0.2）mm |
| Probe diameter | （16±0.05）mm |
| Display | 5 "'color touchscreen |
| printout | Thermal printer |
| Communication interface | RS232 (standard)/USB (optional) |
| Operating Environment | Environmental temperature: (20 +/- 10) ℃; Relative Humidity: < 85% |
| Dimensions | 400*400*530mm |
| Net Weight | About 24kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/28493/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
