Specifications
| Power supply Voltage | AC220V±10%，10A, 50Hz |
| crest radius | R1.50±0.1mm |
| Valley radius | R2.0±0.1mm |
| tooth height | 4.75±0.05mm |
| Gear tooth form | Type A |
| Rotation speed | 4.5rpm |
| Temperature Resolution | 1℃ |
| Temperature adjustable range | RT+~200℃ |
| Working pressure adjustable range | 49~108N |
| Operating temperature | 175±8℃ |
| Dimensions | 530*400*475mm |
| Weight | Approx. 80kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/28513/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
