Specifications
| Resolution | 0.01mm |
| Measurement range | 0~20mm |
| Error of indication | ±0.05mm |
| Indication variability | ≤0.05mm |
| Contact Pressure | 20±0.5kPa |
| Contact area | 10±0.2cm² |
| Measurement plane parallelism | ≤0.035mm |
| Probe descent speed | 2~mm/s |
| Operating Environment | Indoor temperature (20 +/- 10) ℃; Relative Humidity < 85% |
| Dimensions | 170 * 140 * 225Mm (excluding watch head) |
| Weight | 6.8kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/28517/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
