Specifications
| Power supply Voltage | AC220V±10% 2A 50Hz |
| Error of indication | ±0.5%FS |
| Indication variability | ≤0.5% |
| Resolution | 0.1kPa |
| Measurement range | 250~5500kPa |
| Oil delivery speed | 170±15mL/min |
| Clamping Force | ≤1200Kpa |
| Specimen holding system | Upper chuck diameter |
| air source pressure | Rated pressure (0.6~ 0.7) MPa; Displacement Volume (0.02~ 0.3) m3/min (non-standard) |
| Film resistance | Raise 10mm, 170kPa~ 220kPa |
| System sealing | 1Min pressure drop < 10% FS |
| Display | 4.3 "Color touchscreen |
| printout | modular integrated thermal printer |
| Communication interface | RS232 (std.)/USB (optional) |
| Operating Environment | Indoor temperature (20 +/- 10) ℃; Relative Humidity < 85% |
| Dimensions | 535*365*585mm |
| Weight | About 68Kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
